Fomtec AFFF 1% A Foam

Product Description:

Fomtec AFFF 1% A is an aqueous film forming foam concentrate (AFFF) consisting of fluorocarbon and hydrocarbon surfactants blended with various solvents, preservatives and stabilisers. The foam forms an aqueous film that rapidly cuts off the oxygen supply and thus knocks down the fire. The expanded foam from which the film is drained forms a stable blanket that suppresses the release of flammable vapours and cools down the fuel surface extinguishing the fire and preventing re-ignition.

The low surface tension of the water foam concentrate solution enables the aqueous film, although heavier than the burning liquid, to float on top of the liquid surface.

Fomtec AFFF 1% A should be used at 1% proportioned solution (1 part concentrate in 99 parts of water) in fresh or seawater. It may also be stored as a pre-mix solution in fresh water.

Application

Fomtec AFFF 1% A is intended for use on class B hydrocarbon fuel fires such as oil, diesel and aviation fuels. It can be used with both aspirating and non-aspirating discharge devices. Fomtec AFFF 1% A is especially suited whenever rapid-fire knockdown is essential. It is compatible with all dry chemical powders and can be used in powder/foam twin agent systems.

Fire Performance & Foaming

The fire performance of Fomtec AFFF 1% A has been tested and documented according to the UK Ministry of Defence Standard 42/40 and EN 1568 Part 3 at 1% proportioning. Foaming index no less than 7:1 (normally 8:1). 25% drainage time 3.0 minutes (normally 3.5).

Proportioning

Fomtec AFFF 1% A can easily be proportioned at the correct dilution using conventional equipment such as:

Technical data

• Inline inductors.
• Balanced pressure, variable flow proportioning systems.
• Bladder tanks.
• Around the pump proportioning systems.
• Water turbine driven foam proportioners.
• Self-inducting branch pipes and nozzles.

• Appearance Clear Amber Liquid
• Specific gravity @ 20°C 1.02 +/- 0.01 g/ml
• Viscosity approx. @ 20°C < 20 cSt
• pH 7.5 +/- 1.0
• Freezing point - 20°C
• Pour point - 18°C
• Suspended sediment (v/v) Less than 0.2%
• Surface tension approx. 20.0 dynes/cm

International Approvals

Fulfils the requirements of the following standard: EN 1568, part 3
